Airplay on Linux - how it works and what it needs
I've vibe coded DespairPlay GUI - a GTK4 / libadwaita app that inspects the Linux AirPlay sender stack (Avahi, PipeWire RAOP, firewall/mDNS) and shows which parts of this confusing house of cards are installed and active. Yes I could check it via terminal but I forget the ridiculous commands like "raop - v do-thing-pls -c -f", as I don't need to check it often.
Linux can send audio to AirPlay speakers via RAOP (AirPlay 1) but it's a confusing mess. This app diagnoses potential issues instead of just shrugging and recommending “install more packages”. I spaffed this project out after sliding into despair tryng to understand why my soundbar stopped playing music one day.
It does not implement an AirPlay receiver, screen mirroring, or AirPlay 2 sending.
Github
It was developed on Ubuntu 24 and uses libraries included with that. Github link coming soon when I work out how to package it, and see if it works on other flavours of Linux like my Zorin laptop.
So, how does 'Airplay' work on Linux?
This overview covers the arcane steps required to start sending audio to Airplay speakers from Linux (in my case Ubuntu 24/Gnome and ZorinOS). It does not cover screen mirroring, or making your Linux computer into an Airplay receiver.
Airplay can 'hijack' a speaker that is already playing sound from another source, so that can confuse matters. My soundbar is connected to my TV. If I'm playing music from a computer and the TV turns on, it will take the audio over.
Finding Airplay Speakers
On a Mac, Airplay depends on Bonjour which is Apple's name for mDNS (multicast DNS), a 'zero configuration' networking discovery service AKA 'zeroconf'. That's a way to easily find things on your network and enables names like shinymac.local instead of having to type 192.168.1.154 or whatever that is easy to forget. Devices like Airplay speakers broadcast themselves on the local network.
Macs just deal with this behind the scenes, but like many things on Linux we have to set it up manually after spending (too many) hours reading all about it. Linux has to recreate the Bonjour system with mDNS and Avahi. Linux mDNS is handled by Avahi as a daemon, so that needs installing if it's not already there.
Also you might need to open a port on your firewall so it can see the devices broadcasting on your network. Not doing this had me confused for a while.
Sending Audio to Airplay Speakers
Once we've found the Airplay speakers, we need to send something to them.
PulseAudio was the old way of doing audio on Linux. Most systems now use Pipewire, which can also pretend to be PulseAudio for compatibility. Linux audio can also involve ALSA and JACK. OK? OK. PipeWire handles audio natively now while supplying compatibility layers (pipewire-pulse) so old PulseAudio commands still work seamlessly.
Airplay is Apple's newer name for their RAOP (Remote Audio Output Protocol) format. It is the underlying networking protocol Apple created back in 2004 for AirTunes (which was later rebranded to AirPlay).
RAOP is based on the RTSP (Real-Time Streaming Protocol) to establish connections and controls, and then streams audio over UDP using Apple Lossless Audio Codec (ALAC). It's encrypted but the RSA public key stored in iTunes was extracted by Jon Lech Johansen, enabling third-party software to stream music to Airplay devices.
While you can load modules using PulseAudio compatibility utilities like pactl load-module module-raop-discover, modern PipeWire setups typically handle RAOP discovery via PipeWire's native configuration files (specifically loading libpipewire-module-raop-discover via pipewire.conf.d or installing a zeroconf/extras package like pipewire-zeroconf).
Told you it was a mess. I somehow got this working and typed all that stuff above, and it still reads like the ravings of a madman to me.
System Tray Airplay Toggle
There's also a script to add an Airplay speaker toggle to the system tray - bear in mind 'Gnome tweaks' can mess with this though. The Ubuntu version of Gnome really is a bin fire.
https://github.com/craw0967/pipewire-airplay-toggle
